Aries Overlay

Alternating Air Mattresses

aries mattress
  • Designed as an economic prevention for patients at low risk of pressure ulcer
  • Features a clincally proven 1-in-2 cell alternating cycle to prevent long term pressurization of tissues
  • 17 air cell mattress has the option to include low air loss funciton to provide additional comfort for patients
  • Changeable air cells, allow caregiver to deliver maximum comfort for patients.
PumpIIIIVV (ECO)V plus
Weight Setting ControlDial
Dimension27 x 12 x 11.5 cm24 x 11 x 10.5 cm26.5 x 12 x 11 cm26 x 11 x 9.6 cm26 x 12 x 10.5 cm
Weight1.3kg1.3kg1.4kg0.9 kg1.4 kg
Air Output5 liter/min
Case MaterialFlame Retardant Abs
Pressure Range40 - 100 mmHg45 - 110 mmHg40 - 100 mmHg
Cycle Time10 - 12 min
Power SupplyAC 230V/50 Hz ; 120V/60 Hz
MattressEffect 5000Effect 5000 (ECO)
Inflated Dimension190 x 88 x 11 cm
AlternatingA/B Alternating
Structure17 x 4.3" Cells
Cover MaterialNylon/PU with Button
Cell MaterialNylon/PVC
Base MaterialNylon/PVC
Maximum Weight Capacity140 kg130 kg
Flame Retardant StandardsCA 117
End FlapsYES-
Low Air LossOption-


CPR function
  • Allows rapid deflation in case of medical emergencies.
  • Designed for one handed operation
  • Positioned at head end

Pillow Function
  • Head zone comprised of three fully inflated static air cells to provide patient comfort.
