Taurus Overlay

Alternating Air Mattresses

Taurus with watermarked
Taurus with Watermarked 513
  • Designed as the ultimate solution for patients with medium risk of pressure ulcer.
  • Features audio and visual LED indicators, enabling caregivers to easily identify normal and low-pressure levels
  • Utilized water-resistant and vapor permeable Bi-Elastic Nylon/TPU top cover to reduce skin shear and friction
  • Optional foam pocket to provide additional support and comfort for the patients.
PumpAutoIII
Weight Setting ControlDial
Dimension28 x 20 x 10 cm
Weight2.2 kg
Air Output8 liter/min
Case MaterialFlame Retardant Abs
Pressure Range30-60 mmHg40-100 mmHg
Cycle Time10-12 min
Power SupplyAC 230V/50 Hz ; 120V/60 Hz
MattressEffect 5200Effect 4212Effect 5213
Inflated Dimension203 x 90 x 12.7 cm200 x 88 x 11 cm
+ 5 cm foam pocket		203 x 90 x 12.7 cm
+ 7.6 cm foam pocket
AlternatingA/B Alternating or A/B/C Alternating
Structure17 x 5" Cells18 x 4.3" Cells17 x 5" Cells
Cover MaterialNylon/PU with Zipper
Cell MaterialNylon/PVC
Base MaterialNylon/PVC
Maximum Weight Capacity160 kg180 kg
Flame Retardant StandardsCA117CA117/CFR 1632
Quick Connector with Cap
  • Ensures Mattress remains inflated during power outage or patient transport

CPR function
  • Allows rapid deflation in case of medical emergencies.
  • Designed for one handed operation
  • Positioned at head end

Pillow Function
  • Head zone comprised of three fully inflated static air cells to provide patient comfort.

Foam Pocket
  • The unique design allows user to install an additional foam as an effective pressure support base.
